PHOENIX CONTACT FK-MCP 1,5/ 3-ST-3,81 BD3-1 SO FK-MCP 1,5/ 3-ST-3,81 BD3-1 SO 1710299 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FK-MCP 1,5/ 3-ST-3,81 BD3-1 SO 1710299 PHOENIX CONTACT Printed-circuit board connector

FK-MCP 1,5/ 3-ST-3,81 BD3-1 SO

1710299

PHOENIX CONTACT

300 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 1.5 mm², color: green, rated current: 8 A, sizing voltage (III/2): 160 V, surface contacts: Tin, contact type: Connection female, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, article family: FK-MCP 1.5/.. -ST, pitch: 3.81 mm, connection type: Push-in spring connection, connection direction conductor/printed circuit board: 0°, Stecksystem: MINI COMBICON, Lock: sin, packing type: boxed packaging

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1710299
Packing unit1
GTIN4055626141657
Custom tariff number85366990

Dimensions

Length [ l ]21 mm
Width [ w ]12.22 mm
Height [ h ]12.4 mm
Pitch3.81 mm
Dimension a7.62 mm

General

Range of articlesFK-MCP 1,5/..-ST
Number of positions3
Connection methodPush-in spring connection
Insulating material groupI
Rated voltage (III/2)160 V
Nominal current IN8 A
Nominal cross section1.5 mm²
Flammability rating according to UL 94V0

Specifications for ferrules

Recommended crimping pliers1212034 CRIMPFOX 6
Ferrules without insulating collar, according to DIN 46228‑1Cross section: 0.25 mm²; Length: 7 mm ... 9 mm
Cross section: 0.34 mm²; Length: 7 mm ... 9 mm
Cross section: 0.5 mm²; Length: 8 mm ... 9 mm
Cross section: 0.75 mm²; Length: 8 mm ... 9 mm
Cross section: 1 mm²; Length: 8 mm ... 9 mm
Cross section: 1.5 mm²; Length: 8 mm ... 9 mm

Standards and Regulations

Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
