PHOENIX CONTACT PC 5/ 4-GF-7,62 BK PC 5/ 4-GF-7,62 BK 1831921 PHOENIX CONTACT PCB headers, number of positions: 4, pitch: 7.62 mm, color: black View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PC 5/ 4-GF-7,62 BK 1831921 PHOENIX CONTACT PCB headers, number of positions: 4, pitch: 7.62 mm, color: black

PC 5/ 4-GF-7,62 BK

1831921

PHOENIX CONTACT

1 Pcs.


Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
PCB headers, number of positions: 4, pitch: 7.62 mm, color: black

Printed circuit board base case, nominal section: 6 mm², color: black, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of rows: 1, number of poles: 4, family of articles: PC 5/.. -GF, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 5 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 5, Plug-in face orientation: Standard, locking: Screw lock, fixing type: Air clamping (thread), packaging type: boxed

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
