View larger
Images are for illustrative purposes only. Please refer to data sheet for details
PC 5/ 3-G-7,62 BUGY 1705146 PHOENIX CONTACT Base housing, rated current: 41 A, number of poles: 3, pitch: 7...
PC 5/ 3-G-7,62 BUGY
1705146
PHOENIX CONTACT
50 Pcs.
Base housing, rated current: 41 A, number of poles: 3, pitch: 7.62 mm, colour: bluish grey, contact surface: Tin, mounting: Wave solder
Printed circuit board base housing, nominal section: 6 mm², color: bluish gray, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of rows: 1, number of poles: 3, family of items: PC 5/.. -G, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 5 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Header, nominal current: 41 A, number of positions: 3, pitch: 7.62 mm, color: blue grey, contact surface: Tin, mounting: Wave soldering
Your advantages
Well-known mounting principle allows worldwide useStandard header – also suitable for connectors with automatically locking Click and Lock systemMaximum flexibility when it comes to device design – one header for connectors with different connection technologies
General
| Range of articles | PC 5/..-G |
|---|---|
| Rated voltage (III/3) | 630 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 41 A |
| Color | blue grey |
| Number of positions | 3 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
eCl@ss
| eCl@ss 4.0 | 272607xx |
|---|---|
| eCl@ss 4.1 | 27260701 |
| eCl@ss 5.0 | 27260701 |
| eCl@ss 5.1 | 27260701 |
| eCl@ss 6.0 | 27260704 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
UNSPSC
| UNSPSC 6.01 | 30211810 |
|---|---|
| UNSPSC 7.0901 | 39121409 |
| UNSPSC 11 | 39121409 |
| UNSPSC 12.01 | 39121409 |
| UNSPSC 13.2 | 39121409 |
