PHOENIX CONTACT PC 35 HC/ 4-STF-15,00 GY PC 35 HC/ 4-STF-15,00 GY 1704058 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PC 35 HC/ 4-STF-15,00 GY 1704058 PHOENIX CONTACT Printed-circuit board connector

PC 35 HC/ 4-STF-15,00 GY

1704058

PHOENIX CONTACT

25 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 35 mm², color: gray, nominal current: 125 A, nominal voltage (III/2): 1000 V, contact surface: silver, contact type: Female, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: PC 35 HC/.. -STF, pitch: 15 mm, connection type: Screw connection with traction capsule, screw clamping form: L Longitudinal slot, conductor connection direction/printed circuit board: 0 °, clamping hook: - without clamping hook, plug-in system: COMBICON PC 35, locking: Screw locking, fixing type: Air clamping (screw), packaging type: Boxed Packaging

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1704058
Packing unit1
GTIN4046356672894
Custom tariff number85366990

Dimensions

Length [ l ]52 mm
Width [ w ]84.4 mm
Height [ h ]40 mm
Pitch15 mm
Dimension a45 mm

General

Range of articlesPC 35 HC/..-STF
Number of positions4
Connection methodScrew connection with tension sleeve
Rated voltage (III/3)1000 V
Connection in acc. with standardEN-VDE
Nominal current IN125 A
Nominal cross section35 mm²
NoteTightening torque ≤ 25 mm² is 2.5 Nm, > 25 mm² is 4.5 Nm

Connection data

Conductor cross section solid min.0.5 mm²
Conductor cross section solid max.35 mm²
Conductor cross section flexible min.0.5 mm²
Conductor cross section flexible max.35 mm²
Conductor cross section flexible, with ferrule without plastic sleeve min.1 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max.35 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min.1.5 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max.35 mm²
Conductor cross section AWG min.20
Conductor cross section AWG max.2
2 conductors with same cross section, solid min.0.5 mm²
2 conductors with same cross section, solid max.6 mm²
2 conductors with same cross section, stranded min.0.5 mm²
2 conductors with same cross section, stranded max.6 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.0.5 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.4 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.0.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.6 mm²

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
