View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MSTBW 2,5/ 4-G GY 1012678 PHOENIX CONTACT Feed-through header MSTBW 2,5/ 4-G GY 1012678
MSTBW 2,5/ 4-G GY
1012678
PHOENIX CONTACT
50 Pcs.
Feed-through header - MSTBW 2,5/ 4-G GY - 1012678
Printed circuit board base housing, nominal section: 2.5 mm², color: gray, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: MSTBW 2.5/.. -G, pitch: 5 mm, mounting: Wave welding, number of welding pins per potential: 1, plug-in system: CLASSIC COMBICON, Plug-in face orientation: Standard, Locking: without, fixing type: without
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 4, pitch: 5 mm, color: gray, contact surface: Tin, mounting: Wave soldering
Key Commercial Data
| Orderkey | 1012678 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626490243 |
| Custom tariff number | 85366930 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
ETIM
| ETIM 5.0 | EC002637 |
|---|---|
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
