PHOENIX CONTACT MSTBVA 2,5/ 3-G BK PIN15,5 MSTBVA 2,5/ 3-G BK PIN15,5 1805973 PHOENIX CONTACT PCB headers, nominal current: 12 A, rated voltage (III/2).. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MSTBVA 2,5/ 3-G BK PIN15,5 1805973 PHOENIX CONTACT PCB headers, nominal current: 12 A, rated voltage (III/2)..

MSTBVA 2,5/ 3-G BK PIN15,5

1805973

PHOENIX CONTACT

1 Pcs.


Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 3, pitch: 5 mm, color: black, contact surface: Tin, mounting: Wave soldering

Printed circuit board base case, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, family of articles: MSTBVA 2.5/.. -G, pitch: 5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 15.5 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: without, fixing type: without, packaging type: boxed

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
