MSTBVA 2,5/20-G BK 1723706 PHOENIX CONTACT Printed-circuit board connector

MSTBVA 2,5/20-G BK

1723706

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Printed circuit board base housing, nominal section: 2.5 mm², color: black, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, Number of potentials: 20, Number of rows: 1, Number of poles per row: 20, number of connections: 20, family of articles: MSTBVA 2.5/.. -G, pitch: 5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, Stecksystem: CLASSIC COMBICON, Locking: without, packaging type: boxed PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, nominal cross section: 2.5 mm², number of positions: 20, pitch: 5 mm, color: black, contact surface: Tin, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.9 mm

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1723706
Packing unit1 pc
Minimum order quantity50 pc
GTIN4046356122870
Weight per Piece (excluding packing)8.800 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]8.57 mm
Width102 mm
Pitch5 mm
Dimension a95 mm
Width [ w ]102 mm
Height [ h ]15.9 mm
Height12 mm
Length of the solder pin3.9 mm
Length8.57 mm
Back to top

General

Range of articlesMSTBVA 2,5/..-G
Rated voltage (III/3)250 V
Connection in acc. with standardEN-VDE
Nominal current IN12 A
Colorblack
Number of positions20
