PHOENIX CONTACT MSTBV 2,5/19-G BK MSTBV 2,5/19-G BK 1755419 PHOENIX CONTACT Housing base for printed circuit board, nominal current: 12 A, num.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MSTBV 2,5/19-G BK 1755419 PHOENIX CONTACT Housing base for printed circuit board, nominal current: 12 A, num..

MSTBV 2,5/19-G BK

1755419

PHOENIX CONTACT

50 Pcs.

Housing base for printed circuit board, nominal current: 12 A, number of poles: 19, pitch: 5 mm, color: black, surface of contact: Tin, assembly: wave Soldering Printed circuit board base housing, nominal section: 2.5 mm², color: black, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, Number of potentials: 19, Number of rows: 1, Number of poles per row: 19, number of connections: 19, family of articles: MSTBV 2.5/.. -G, pitch: 5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, Stecksystem: CLASSIC COMBICON, Locking: without, packaging type: boxed PCB socket, nominal cross-section: 2.5 mm2, colour: black, rated current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Sn, contact connection type: plug, number of potentials: 19, number of rows: 1, number of poles: 19, number of connections: 19, product series: MSTBV 2.5/.. -G, pitch: 5 mm, mounting: Wave soldering, pin layout: Linear pinning, pin length [P]: 3.9 mm, number of solder pins per potential: 1, plug system: COMBICON MSTB 2.5, Insertion pin orientation: Standard, locking: none, fixing type: none, packaging type: packed in carton

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Article features
Product TypeBasic socket for printed circuit boards
Product FamilyMSTBV 2.5/.. -G
Product LineCOMBICON Connectors M
Number of poles19
Step5 mm
Number of connections19
Number of rows1
Number of potentials19
Fixing flangeabsent
Pin LayoutLinear Pinning
Number of Welding Pins per Potential1
Data maintenance status
Article review01
Electrical characteristics
Rated Current IN12 A
Rated voltage UN320 V
Mass Resistivity2.1 mΩ
Sizing voltage (III/3)250 V
Sizing impulse voltage (III/3)4 kV
Sizing voltage (III/2)320 V
Sizing Impulse Voltage (III/2)4 kV
Sizing voltage (II/2)400 V
Sizing Impulse Voltage (II/2)4 kV
Montage
Mounting typeWave Soldering
Pin LayoutLinear Pinning
Material information
Material information - contacts
noteComplies with WEEE/RoHS, no thread-like materials according to IEC 60068-2-82/JEDEC JESD 201
Contact MaterialCu Alloy
Surface FinishGalvanic tin plating
Metal surface contact zone (surface layer)Tin (3 - 5 μm Sn)
Metal surface contact area (middle layer)Nickel (1.3 - 3 μm Ni)
Metal Surface Welding Area (Surface Layer)Tin (3 - 5 μm Sn)
Metal Surface Weld Area (Middle Layer)Nickel (1.3 - 3 μm Ni)
Material information - case
Color (Case)Black (9005)
Insulation materialPBT
Insulation Material GroupIIIa
CTI according to IEC 60112225
Combustibility class according to UL 94V0
Notes
Note for OperationAccording to DIN EN 61984, COMBICON connectors are connectors without switchable power (COC). For use in accordance with the intended use, they must not be switched on or disconnected while they are still live or under load.
dimensions
Dimensioned Drawingdvbtjqggdc.jpg
Step5 mm
Width [w]95 mm
Height [h]15.9 mm
Length [l]8.57 mm
Installation Height12 mm
Weld Shank Length [P]3.9 mm
Shank sizes1 x 1 mm
Printed circuit board design
Bore diameter1.4 mm
Mechanical Controls
Visual inspection
Test SpecificationDIN EN 60512-1-1:2003-01
ResultTest passed
Dimensional control
Test SpecificationDIN EN 60512-1-2:2003-01
ResultTest passed
Resistance of lettering
Test SpecificationDIN EN 60068-2-70:1996-07
ResultTest passed
Polarization and encoding
Test SpecificationDIN EN 60512-13-5:2006-11
ResultTest passed
Contact holder in use
Test SpecificationDIN EN 60512-15-1:2009-03
Areas of application for contact holders
Application >20 N		Test passed
Insertion/tensile force
ResultTest passed
Number of cycles25
Insertion force per pole approx.8 N
Tensile force per pole approx.6 N
Electrical Controls
Thermal Test Control Group C
Test SpecificationDIN EN 60512-5-1:2003-01
Number of poles tested18
Insulation Resistance
Test SpecificationDIN EN 60512-3-1:2003-01
Insulation Resistance Between Contiguous Poles> 5 MΩ
Creepage and Creepage Distances
Test SpecificationDIN EN 60664-1 (VDE 0110-1):2008-01
Insulation Material GroupIIIa
Resistance to surface currents (DIN EN 60112 (VDE 0303-11))CTI 225
Rated insulation voltage (III/3)250 V
Rated impulse voltage (III/3)4 kV
Minimum clearance value - inhomogeneous range (III/3)3 mm
Minimum creepage value (III/3)4 mm
Rated Isolation Voltage (III/2)320 V
Rated impulse voltage (III/2)4 kV
Minimum creepage value - inhomogeneous range (III/2)3 mm
Minimum creepage value (III/2)3.2 mm
Rated Isolation Voltage (II/2)400 V
Rated Impulse Voltage (II/2)4 kV
Minimum creepage value - inhomogeneous range (II/2)3 mm
Minimum creepage value (II/2)4 mm
Environmental and electrical life conditions
Vibration test
Test SpecificationDIN EN 60068-2-6 (VDE 0468-2-6):2008-10
Frequency10 - 150 - 10 Hz
Sweep Speed1 octave/min
Amplitude0.35 mm (10 Hz ... 60.1 Hz)
Acceleration5g (60.1 Hz ... 150 Hz)
Test duration per axle2.5 h
Test DirectionsX, Y, and Z axis
Electrical life control
Test SpecificationDIN EN 60512-9-1 (VDE 0687-512-9-1):2010-12
Vertical impulse tension above sea level4.8 kV
Mass Resistivity R12.1 mΩ
Mass Resistivity R22.3 mΩ
Manoeuvring cycles25
Insulation Resistance Between Contiguous Poles> 5 MΩ
Climate control
Test SpecificationDIN EN ISO 6988:1997-03
Stress due to corrosion0.2 dm3KNOW2on 300 dm3/40 °C/1 cycle
Stress due to the effect of heat100 °C/168 h
Fixed AC voltage2.21 kV
Environmental conditions
Ambient temperature (operating)-40 °C ... 100 °C (depending on derating curve)
Ambient temperature (storage/transport)-40 °C ... 70 °C
Relative humidity (transport and storage)30 % ... 70 %
Ambient temperature (mounting)-5 °C ... 100 °C
Packaging Information
PackagingPacked in carton
