PHOENIX CONTACT FK-MPT 0,5/ 8-ST-3,5 BD:V-A,B FK-MPT 0,5/ 8-ST-3,5 BD:V-A,B 1701578 PHOENIX CONTACT Plug

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

FK-MPT 0,5/ 8-ST-3,5 BD:V-A,B 1701578 PHOENIX CONTACT Plug

Name: FK-MPT 0,5/ 8-ST-3,5 BD:V-A,B 1701578 PHOENIX CONTACT Plug
Brand: PHOENIX CONTACT
SKU: 1701578

Reference: FK-MPT 0,5/ 8-ST-3,5 BD:V-A,B

Code: 1701578

Manufacturer: PHOENIX CONTACT

Units per package: 50 Pcs.

Description:

Plug Connector for printed circuit board, nominal section: 0.5 mm², color: green, nominal current: 4 A, dimensioning voltage (III/2): 250 V, contact surface: Tin, contact type: Female connection, Number of potentials: 8, Number of rows: 1, Number of poles per row: 8, number of connections: 16, article family: FK-MPT 0.5/.. -ST, pitch: 3.5 mm, connection type: Push-in spring connection, conductor/printed circuit board connection direction: 0 °, pin arrangement: Linear pin arrangement, Stecksystem: COMBICON COMPACT PST 1, Lock: without, packaging type: boxed

Categories:
Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Key Commercial Data

Orderkey	1701578
Packing unit	1
GTIN	4046356544870
Custom tariff number	85366990

Dimensions

Length [ l ]	9.5 mm
Width [ w ]	28.5 mm
Height [ h ]	8.5 mm
Pitch	3.5 mm
Dimension a	24.5 mm

General

Range of articles	FK-MPT 0,5/..-ST
Number of positions	8
Connection method	Push-in spring connection
Rated voltage (III/3)	160 V
Connection in acc. with standard	EN-VDE
Nominal current I_N	4 A
Nominal cross section	0.5 mm²

Connection data

Conductor cross section solid min.	0.12 mm²
Conductor cross section solid max.	0.5 mm²
Conductor cross section AWG min.	26
Conductor cross section AWG max.	20
Minimum AWG according to UL/CUL	28
Maximum AWG according to UL/CUL	20
