View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MSTBAW 2,5/ 6-G-5,08 BK 1700930 PHOENIX CONTACT Printed-circuit board connector
MSTBAW 2,5/ 6-G-5,08 BK
1700930
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Width | 37.56 mm |
| Pitch | 5.08 mm |
| Dimension a | 30.48 mm |
| Width [ w ] | 37.56 mm |
| Height [ h ] | 15.62 mm |
| Height | 12.42 mm |
| Length of the solder pin | 3.2 mm |
| Pin dimensions | 1 x 1 mm |
| Length | 12 mm |
General
| Range of articles | MSTBAW 2,5/..-G |
|---|---|
| Rated voltage (III/3) | 250 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 12 A |
| Color | black |
| Number of positions | 6 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
