PHOENIX CONTACT MSTBA 2,5 HC/ 2-GU MSTBA 2,5 HC/ 2-GU 1752492 PHOENIX CONTACT Feed-through header

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

MSTBA 2,5 HC/ 2-GU 1752492 PHOENIX CONTACT Feed-through header

Name: MSTBA 2,5 HC/ 2-GU 1752492 PHOENIX CONTACT Feed-through header
Brand: PHOENIX CONTACT
SKU: 1752492

Reference: MSTBA 2,5 HC/ 2-GU

Code: 1752492

Manufacturer: PHOENIX CONTACT

Units per package: 50 Pcs.

Description:

Feed-through header Printed circuit board base housing, nominal section: 2.5 mm², color: green, contact surface: Tin, contact type: Male, Number of potentials: 2, Number of rows: 1, Number of poles per row: 2, number of connections: 2, family of articles: MSTBA 2.5 HC/.. -GU, pitch: 5 mm, mounting: Wave welding, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, Stecksystem: POWER COMBICON 2.5, Locking: without, packaging type: boxed

Categories:
Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Key Commercial Data

Orderkey	1752492
Packing unit	50 pc
Minimum order quantity	50 pc
Note	Made to Order (non-returnable)
GTIN	4046356320771
Weight per Piece (excluding packing)	0.860 g
Custom tariff number	85366930
Country of origin	DE (Germany)

Dimensions

Length [ l ]	12 mm
Width	12 mm
Pitch	5 mm
Dimension a	5 mm
Width [ w ]	12 mm
Height [ h ]	12.1 mm
Height	8.6 mm
Length of the solder pin	3.5 mm
Length	12 mm

General

Range of articles	MSTBA 2,5 HC/..-GU
Rated voltage (III/3)	250 V
Connection in acc. with standard	EN-VDE
Nominal current I_N	16 A
Color	green
Number of positions	2
