View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MSTB 2,5/ 6-GF-5,08 BK AU 1098428 PHOENIX CONTACT PCB headers, number of positions: 6, pitch: 5.08 mm, color..
MSTB 2,5/ 6-GF-5,08 BK AU
1098428
PHOENIX CONTACT
1000 Pcs.
PCB headers, number of positions: 6, pitch: 5.08 mm, color: black, contact surface: Gold, pin layout: Linear pinning, solder pin [P]: 3.5 mm
Printed circuit board base case, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Gold, contact type: Male, number of rows: 1, number of poles: 6, family of articles: MSTB 2.5/.. -GF, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: Screw lock, fixing type: Air clamping (thread), packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Key Commercial Data
| Orderkey | 1098428 |
|---|---|
| Packing unit | 1 pc |
| Minimum order quantity | 1000 pc |
| GTIN | 4055626942919 |
| Weight per Piece (excluding packing) | 4.200 g |
| Custom tariff number | 85366930 |
| Country of origin | DE (Germany) |
Item properties
| Number of positions | 6 |
|---|---|
| Drive form screw head | Slotted (L) |
| Pin layout | Linear pinning |
Dimensions for the product
| Length [ l ] | 12 mm |
|---|---|
| Width [ w ] | 40.64 mm |
| Height [ h ] | 12.1 mm |
| Pitch | 5.08 mm |
| Height (without solder pin) | 8.6 mm |
| Solder pin [P] | 3.5 mm |
| Dimension a | 25.4 mm |
Packaging information
| Type of packaging | packed in cardboard |
|---|---|
| Pieces per package | 100 |
| Denomination packing units | Pcs. |
Classifications
| Feature Name | Feature Value |
|---|---|
| Connector model (EF007495) | Fixed connector |
| Contact type (EF001587) | Pin |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 5.08 mm |
| Modular spacing connections (EF006827) | 5.08 mm |
| Rated current In (EF008250) | 12 A |
| Rated voltage (EF000228) | 320 V |
| Rated surge voltage (EF002993) | 4 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Material of contact surface (EF004020) | Gold |
| Type of electric connection (EF003961) | Other |
| Diameter connection pin (EF006823) | 1.4 mm |
| Length pin (EF006825) | 3.23 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Black |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of fastening (EF002442) | Other |
| Type of banding (EF007011) | Carton (for SMD) |
