PHOENIX CONTACT MSTB 2,5/ 3-ST-5,08 BU BDWH3-1 MSTB 2,5/ 3-ST-5,08 BU BDWH3-1 1751147 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MSTB 2,5/ 3-ST-5,08 BU BDWH3-1 1751147 PHOENIX CONTACT Printed-circuit board connector

MSTB 2,5/ 3-ST-5,08 BU BDWH3-1

1751147

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 2.5 mm², color: blue, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, family of articles: MSTB 2.5/.. -ST, pitch: 5.08 mm, connection type: Screw connection with traction capsule, screw clamping form: L Longitudinal slot, conductor connection direction/printed circuit board: 0 °, Clamping hook: - Clamping hook, plug-in system: CLASSIC COMBICON, Locking: without, fixing type: without, packaging type: packed in box
