PHOENIX CONTACT MSTB 2,5/ 3-G KMGY MSTB 2,5/ 3-G KMGY 1937716 PHOENIX CONTACT Printed-circuit board connector

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

MSTB 2,5/ 3-G KMGY 1937716 PHOENIX CONTACT Printed-circuit board connector

Name: MSTB 2,5/ 3-G KMGY 1937716 PHOENIX CONTACT Printed-circuit board connector
Brand: PHOENIX CONTACT
SKU: 1937716

Reference: MSTB 2,5/ 3-G KMGY

Code: 1937716

Manufacturer: PHOENIX CONTACT

Units per package: 50 Pcs.

Description:

Printed-circuit board connector Base housing printed circuit board, nominal section: 2.5 mm², colour: light grey, rated current: 12 A, sizing voltage (III/2): 320 V, surface contacts: Tin, contact type: Male, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, item family: MSTB 2.5/.. -G, pitch: 5 mm, mounting: Wave welding, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, Stecksystem: CLASSIC COMBICON, Locking: sin, packing type: boxed packaging

Categories:
Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Key Commercial Data

Orderkey	1937716
Packing unit	50 pc
Minimum order quantity	50 pc
GTIN	4017918732493
Weight per Piece (excluding packing)	0.960 g
Custom tariff number	85366930
Country of origin	DE (Germany)

Dimensions

Length [ l ]	12 mm
Width	15 mm
Pitch	5 mm
Dimension a	10 mm
Width [ w ]	15 mm
Height [ h ]	12.1 mm
Height	8.6 mm
Length of the solder pin	3.5 mm
Pin dimensions	1 x 1 mm
Length	12 mm

General

Range of articles	MSTB 2,5/..-G
Rated voltage (III/3)	250 V
Connection in acc. with standard	EN-VDE
Nominal current I_N	12 A
Color	light gray
Number of positions	3
