PTSA 1,5/ 4-3,5-Z MIX YE/BK 1711558 PHOENIX CONTACT Spring-cage PCB terminal block
PTSA 1,5/ 4-3,5-Z MIX YE/BK
1711558
PHOENIX CONTACT
220 Pcs.
Spring-cage PCB terminal block
Terminal block for printed circuit board, nominal current: 8 A, dimensioning voltage (III/2): 400 V, nominal cross-section: 1.5 mm², Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, article family: PTSA 1.5, pitch: 3.5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45 °, color: multicolor, Pin arrangement: Zigzag Pins M, Pin length [P]: 3.6 mm, packaging type: boxed packaging. Welding pins in the anterior area, one row
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 3.5 mm |
| Dimension a | 3.5 mm |
| Width [ w ] | 8.5 mm |
| Height | 13.1 mm |
| Height [ h ] | 16.7 mm |
| Solder pin [P] | 3.6 mm |
| Pin spacing | 3.5 mm |
| Hole diameter | 1 mm |
General
| Range of articles | PTSA 1,5 |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 250 V |
| Nominal current IN | 8 A |
| Nominal cross section | 1.5 mm² |
| Solder pin surface | |
| Flammability rating according to UL 94 | V0 |
| Number of positions | 4 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
