View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MKDSN 2,5/ 4 HT BK PIN21 R44 1018851 PHOENIX CONTACT PCB terminal block MKDSN 2,5/ 4 HT BK PIN21 R44 1018851
MKDSN 2,5/ 4 HT BK PIN21 R44
1018851
PHOENIX CONTACT
140 Pcs.
PCB terminal block - MKDSN 2,5/ 4 HT BK PIN21 R44 - 1018851
Terminal block for printed circuit board, nominal current: 16 A, dimensioning voltage (III/2): 320 V, nominal section: 2.5 mm², Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, family of articles: MKDSN 2.5/.. -HT, pitch: 5mm, connection type: Screw connection with traction capsule, mounting: THR welding, conductor/PCB connection direction: 0°, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 2.1mm, packaging type: 44mm wide strap
PCB terminal block, nominal current: 16 A, rated voltage (III/2): 320 V, nominal cross section: 2.5 mm², pitch: 5 mm, number of positions: 4, connection method: Screw connection with tension sleeve, mounting: THR soldering, conductor/PCB connection direction: 0 °, color: black, Pin layout: Linear pinning, Solder pin [P]: 2.1 mm
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 9.5 mm |
|---|---|
| Pitch | 5 mm |
| Dimension a | 15 mm |
| Width [ w ] | 20 mm |
| Height | 15 mm |
| Height [ h ] | 17.1 mm |
| Solder pin [P] | 2.1 mm |
| Pin spacing | 5 mm |
| Hole diameter | 1.3 mm |
General
| Range of articles | MKDSN 2,5/..-HT |
|---|---|
| Nominal cross section | 2.5 mm² |
| Solder pin surface | |
| Number of positions | 4 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 years |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss
| eCl@ss 5.1 | 27261100 |
|---|---|
| eCl@ss 6.0 | 27261100 |
| eCl@ss 7.0 | 27440401 |
| eCl@ss 8.0 | 27440401 |
| eCl@ss 9.0 | 27440401 |
