PHOENIX CONTACT MKDS-SET 5 78 20 EAZ-TFT45 MKDS-SET 5 78 20 EAZ-TFT45 1711989 PHOENIX CONTACT PCB terminal block, nominal current: 10 A, rated voltage .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MKDS-SET 5 78 20 EAZ-TFT45 1711989 PHOENIX CONTACT PCB terminal block, nominal current: 10 A, rated voltage ..

MKDS-SET 5 78 20 EAZ-TFT45

1711989

PHOENIX CONTACT

1 Pcs.

PCB terminal block, nominal current: 10 A, rated voltage (III/2): 200 V, nominal cross section: 1 mm², pitch: 3.5 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 35 °, color: green Plug-in connector set, Plug-in connector set, article family: SET Connector set, product range: SET

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Product properties
Product typeConnector set
Product familySET
Number of positions1
Pitch0 mm
Data management status
Article revision00
Dimensions
Pitch0 mm
Packaging specifications
Type of packagingpacked in cardboard
