PHOENIX CONTACT MKDS 10 HV/ 1-F-10,16 BN MKDS 10 HV/ 1-F-10,16 BN 1705211 PHOENIX CONTACT Terminal for printed circuit board, nominal current: 76 A, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MKDS 10 HV/ 1-F-10,16 BN 1705211 PHOENIX CONTACT Terminal for printed circuit board, nominal current: 76 A, ..

MKDS 10 HV/ 1-F-10,16 BN

1705211

PHOENIX CONTACT

50 Pcs.

Terminal for printed circuit board, nominal current: 76 A, nominal voltage: 1000 V, pitch: 10.16 mm, number of poles: 1, connection type: Screw connection with traction capsule, mounting: Wave soldering, conductor/printed circuit board connection direction: 0 °, color: brown Terminal for printed circuit board, nominal voltage (III/2): 400 V, number of potentials: 1, number of poles per row: 1, article family: MKDS 10 HV, pitch: 10.16 mm, screw clamping shape: L Longitudinal slot, color: brown, Pin arrangement: Linear rear pin arrangement, Pin length [P]: 5 mm, Number of Welding Pins per Potential: 2, Packaging Type: Boxed Packaging

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, pitch: 10.16 mm, number of positions: 1, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: brown

General

Range of articlesMKDS 10 HV
Rated surge voltage (III/3)8 kV
Rated surge voltage (III/2)8 kV
Rated surge voltage (II/2)8 kV
Rated voltage (III/3)800 V
Rated voltage (III/2)1000 V
Rated voltage (II/2)1000 V
Connection in acc. with standardEN-VDE
Nominal current IN76 A
Nominal cross section10 mm²
Solder pin surfaceSn
Internal cylindrical gageB6
Stripping length10 mm
Number of positions1
Screw threadM4
Tightening torque, min1.2 Nm
Tightening torque max1.5 Nm

Connection data

Conductor cross section AWG min.20
Conductor cross section AWG max.6
2 conductors with same cross section, solid min.0.5 mm²
2 conductors with same cross section, solid max.6 mm²
2 conductors with same cross section, stranded min.0.5 mm²
2 conductors with same cross section, stranded max.6 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.0.5 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.4 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.0.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.6 mm²

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”

eCl@ss

eCl@ss 4.027141109
eCl@ss 4.127141109
eCl@ss 5.027141190
eCl@ss 5.127141190
eCl@ss 6.027261101
eCl@ss 7.027440401
eCl@ss 8.027440401
eCl@ss 9.027440401

ETIM

ETIM 3.0EC001121
ETIM 4.0EC002643
ETIM 5.0EC002643
ETIM 6.0EC002643

UNSPSC

UNSPSC 6.0130211801
UNSPSC 7.090139121432
UNSPSC 1139121432
UNSPSC 12.0139121432
UNSPSC 13.239121432

ETIM for 1705211 Connectors (EC002643)
Feature Name Feature Value
Height (EF000040) 35.8 mm
Number of electrical connections (EF008252) 1
Modular spacing connections (EF006827) 10.16 mm
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connection type conductor (EF006821) Screw connection
Connection type PCB (EF006822) Soldering connection
Diameter connection pin (EF006823) 1.5 mm
Length pin (EF006825) 5 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Brown
Inflammability class of insulation material according to UL94 (EF002521) V0
Type of banding (EF007011) Carton (for SMD)
