PHOENIX CONTACT MKDS 1/ 2-3,81 HT BK R24 MKDS 1/ 2-3,81 HT BK R24 1003562 PHOENIX CONTACT Terminal for printed circuit board, rated voltage: 200 V, p.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MKDS 1/ 2-3,81 HT BK R24 1003562 PHOENIX CONTACT Terminal for printed circuit board, rated voltage: 200 V, p..

MKDS 1/ 2-3,81 HT BK R24

1003562

PHOENIX CONTACT

280 Pcs.

Terminal for printed circuit board, rated voltage: 200 V, pitch: 3,81 mm, number of poles: 2, type of connection: Connection by screw with capsule-traction, assembly: Soldering THR, color: black Terminal block for printed circuit board, nominal current: 13.5 A, nominal voltage (III/2): 200 V, nominal section: 1.5 mm², number of potentials: 2, number of rows: 1, number of poles per row: 2, family of articles: MKDS 1/.. -HT, pitch: 3.81 mm, connection type: Screw connection with traction capsule, screw clamping shape: L Longitudinal slot, mounting: Weld THR, conductor/printed circuit board connection direction: 0 °, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, Packing Type: 24mm Wide Strap

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Terminal for printed circuit board, rated current: 13,5 A, rated voltage: 200 V, pitch: 3,81 mm, number of poles: 2, type of connection: Connection by screw with capsule-traction, assembly: Soldering THR, direction for connection conductor/pcb: 0 °, color: black

Data commercial

Key orderOne million three thousand five hundred sixty two
Packing unit280 pcs
Key sellingAAABCA -
Minimum order quantity280 pcs
EANFour trillion fifty five billion six hundred twenty six million four hundred seventy one thousand one hundred ninety eight
Unit weight (excluding packaging)2,600 g
Tariff number tariffEighty five million three hundred sixty nine thousand ten
