PHOENIX CONTACT ME MAX 45 MT U-U1 KMGY ME MAX 45 MT U-U1 KMGY 2200027 PHOENIX CONTACT DIN rail box, Intermediate element, high design, with ventila.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

ME MAX 45 MT U-U1 KMGY 2200027 PHOENIX CONTACT DIN rail box, Intermediate element, high design, with ventila..

ME MAX 45 MT U-U1 KMGY

2200027

PHOENIX CONTACT

50 Pcs.

DIN rail box, Intermediate element, high design, with ventilation slits, width: 22.6 mm, height: 99 mm, depth: 112.85 mm, color: light gray (similar RAL 7035) Rail box, Middle element, tall design, with ventilation slits, width: 22.6 mm, height: 99 mm, depth: 112.85 mm, colour: light grey (7035) DIN rail housing, intermediate element, high design, with air vents, width: 22.6 mm, height: 99 mm, depth: 112.85 mm, colour: light grey (7035)

Automation > Extruded profile modular housing
Housing (HS)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
GeneralPlease refer to the family data sheet in the download area.
Product TypeComplete housing middle section
Product familyME MAX.. U-U1
Number of rows1
ExecutionIntermediate element, high design
Housing typeDIN rail housing
Ventilation opening availableYes
Housing seriesME-MAX
Width22.6 mm
Height99 mm
Depth112.85 mm
Depth from top edge of the DIN rail107 mm
ColorLight Grey (7035)
Color (Housing)light grey (RAL 7035)
Flammability class according to UL 94V0
CTI according to IEC 60112600
Surface finishuntreated
Material housingPolyamide
Environmental conditions
Maximum IP code that can be reachedIP20
Ambient temperature (operating)-40 °C ... 105 °C (depending on power dissipation)
Ambient temperature (storage/transport)-40 °C ... 55 °C
Ambient temperature (mounting)-5 °C ... 100 °C
Relative humidity (storage/transport)80 %
Type of PCB mountingLatching
Mounting typeDIN rail mounting

ETIM for 2200027 Low-voltage industrial controls and switchgear (EC002779)
Feature Name Feature Value
Type of enclosure (EF003086) Open
Housing connectable (EF003088) No
Suitable for rail mounting (EF003972) No
Wall mounting possible (EF003973) No
With integrated PCB-mounting connection system (EF003087) No
Material (EF002169) Other
Surface finishing (EF006569) Other
RAL-number (EF000116) 7035
Width (EF000008) 22.6 mm
Height (EF000040) 99 mm
Depth (EF000049) 112.85 mm
