PHOENIX CONTACT MDSTBV 2,5/12-G-5,08 BK MDSTBV 2,5/12-G-5,08 BK 1800781 PHOENIX CONTACT Printed-circuit board connector

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

MDSTBV 2,5/12-G-5,08 BK 1800781 PHOENIX CONTACT Printed-circuit board connector

Name: MDSTBV 2,5/12-G-5,08 BK 1800781 PHOENIX CONTACT Printed-circuit board connector
Brand: PHOENIX CONTACT
SKU: 1800781

Reference: MDSTBV 2,5/12-G-5,08 BK

Code: 1800781

Manufacturer: PHOENIX CONTACT

Units per package: 50 Pcs.

Description:

Printed-circuit board connector Printed circuit board base case, nominal section: 2.5 mm², color: black, nominal current: 10 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 24, number of rows: 2, number of poles: 12, number of connections: 24, family of articles: MDSTBV 2.5/.. -G, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: without, fixing type: without, packaging type: boxed

Categories:
Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Key Commercial Data

Orderkey	1800781
Packing unit	50 pc
Minimum order quantity	50 pc
GTIN	4017918937720
Weight per Piece (excluding packing)	16.910 g
Custom tariff number	85366930
Country of origin	DE (Germany)

Dimensions

Length [ l ]	23.69 mm
Width	62.52 mm
Pitch	5.08 mm
Dimension a	55.88 mm
Width [ w ]	62.52 mm
Height [ h ]	25.5 mm
Height	22 mm
Length of the solder pin	3.5 mm
Pin dimensions	1 x 1 mm
Length	23.69 mm

General

Range of articles	MDSTBV 2,5/..-G
Rated voltage (III/3)	250 V
Connection in acc. with standard	EN-VDE
Nominal current I_N	10 A
Color	black
Number of positions	12
