View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MDSTB 2,5/12-G-5,08 GY 1703450 PHOENIX CONTACT Printed-circuit board connector
MDSTB 2,5/12-G-5,08 GY
1703450
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Printed circuit board base housing, nominal section: 2.5 mm², color: gray, nominal current: 10 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, Number of potentials: 24, Number of rows: 2, Number of poles per row: 12, number of connections: 24, family of articles: MDSTB 2.5/.. -G, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.2 mm, Stecksystem: CLASSIC COMBICON, Locking: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 22.1 mm |
|---|---|
| Width | 63.5 mm |
| Pitch | 5.08 mm |
| Dimension a | 55.88 mm |
| Width [ w ] | 63.5 mm |
| Height [ h ] | 27.2 mm |
| Height | 24 mm |
| Length of the solder pin | 3.2 mm |
| Pin dimensions | 1 x 1 mm |
| Length | 22.1 mm |
General
| Range of articles | MDSTB 2,5/..-G |
|---|---|
| Rated voltage (III/3) | 250 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 10 A |
| Color | gray |
| Number of positions | 12 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
