PHOENIX CONTACT MCVR 1,5/ 5-STF-3,5 BK MCVR 1,5/ 5-STF-3,5 BK 1748008 PHOENIX CONTACT Part plug,nominal Current: 8 A,N. º poles: 5,Pitch: 3.5 mm,Te.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCVR 1,5/ 5-STF-3,5 BK 1748008 PHOENIX CONTACT Part plug,nominal Current: 8 A,N. º poles: 5,Pitch: 3.5 mm,Te..

MCVR 1,5/ 5-STF-3,5 BK

1748008

PHOENIX CONTACT

50 Pcs.

Part plug,nominal Current: 8 A,N. º poles: 5,Pitch: 3.5 mm,Technique of connection: Connection by screw with capsule-traction,Color: black,contact Surface: Tin Connector for printed circuit board, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Female, number of potentials: 5, number of rows: 1, number of poles: 5, number of connections: 5, family of articles: MCVR 1.5/.. -STF, pitch: 3.5 mm, connection type: Screw connection with traction capsule, screw clamping shape: L Longitudinal slot, conductor connection direction/printed circuit board: 90 °, plug-in system: COMBICON MC 1.5, lock: Screw lock, fixing type: Air clamping (screw), packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Data commercial

Key orderOne million seven hundred forty eight thousand eight
Packing unit50 pcs
Key sellingAAAEBA -
Minimum order quantity50 pcs
EANFour trillion forty six billion three hundred fifty six million three hundred thousand fifty six
Unit weight (excluding packaging)4,584 g
Tariff number tariffEighty five million three hundred sixty six thousand nine hundred ninety
Country of origin(Germany)

Dimensions

Length [ l ]10,4 mm
Width [ w ]27.9 mm
Height [ h ]19.1 mm
Step3.5 mm
Average14 mm

Overview

Family of articlesMCVR 1,5/..-STF
Number of polesFive
Type of connectionConnection by screw with capsule-traction
Tension and sizing (III/3)160 V
Connection according to standardEN-VDE
Nominal current IN8 To
Nominal cross section1.5 mm2

Data connection

Core cross-section rigid min.0.14 mm2
Section of conductor rigid max.1.5 mm2
Section of flexible conductor, min.0.14 mm2
Section of flexible conductor max.1.5 mm2
Section of flexible conductor with toe cap, without plastic sleeve min.0.25 mm2
Section of flexible conductor with toe cap, without plastic sleeve max.1.5 mm2
Section of flexible conductor with toe, with plastic sleeve min.0.25 mm2
Section of flexible conductor with toe, with plastic sleeve max.0.5 mm2
Section of conductor AWG min.Twenty eight
Section of conductor AWG max.Sixteen
2 conductors with same cross section, rigid min.0,08 mm2
2 conductors with same cross section, rigid max.0.5 mm2
2 conductors with same cross section, flexible, min.0,08 mm2
2 conductors with same cross section, flexible max.0.75 mm2
2 conductors with same cross section, flexible with AEH without plastic sleeve min.0.25 mm2
2 conductors with same cross section, flexible with AEH without plastic sleeve max.0,34 mm2
2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min.0.5 mm2
2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max.0.5 mm2
AWG according to UL/CUL min.Thirty
AWG according to UL/CUL max.Fourteen

Standards and specifications

Connection according to standardEN-VDE
CUL

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSSpace of time for the intended use (FEUP): 50 years
You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab

Ratings


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
