View larger
Images are for illustrative purposes only. Please refer to data sheet for details
IPC 5/ 2-G-7,62 BK 1710835 PHOENIX CONTACT Feed-through header
IPC 5/ 2-G-7,62 BK
1710835
PHOENIX CONTACT
500 Pcs.
Feed-through header
Printed circuit board base housing, nominal section: 6 mm², color: black, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Female, number of potentials: 2, number of rows: 1, number of poles: 2, number of connections: 2, family of articles: IPC 5/.. -G, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 5 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 30.1 mm |
|---|---|
| Width | 15.24 mm |
| Pitch | 7.62 mm |
| Dimension a | 7.62 mm |
| Width [ w ] | 15.24 mm |
| Height [ h ] | 17.8 mm |
| Height | 12.8 mm |
| Length of the solder pin | 5 mm |
| Pin dimensions | 0.8 x 1.2 mm |
| Pin spacing | 7.62 mm |
| Length | 30.1 mm |
General
| Range of articles | IPC 5/..-G |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 630 V |
| Nominal current IN | 41 A |
| Flammability rating according to UL 94 | V0 |
| Color | black |
| Number of positions | 2 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
| Feature Name | Feature Value |
|---|---|
| Connector model (EF007495) | Fixed connector |
| Contact type (EF001587) | Bus |
| Number of poles (EF001391) | 2 |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 7.62 mm |
| Modular spacing connections (EF006827) | 7.62 mm |
| Rated current In (EF008250) | 41 A |
| Rated voltage (EF000228) | 630 V |
| Rated surge voltage (EF002993) | 6 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Material of contact surface (EF004020) | Tin |
| Type of electric connection (EF003961) | Other |
| Diameter connection pin (EF006823) | 1.3 mm |
| Length pin (EF006825) | 5 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Black |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of fastening (EF002442) | Other |
| Type of banding (EF007011) | Carton (for SMD) |
