> PHOENIX CONTACT > PCB Connectors (PCC) > 1711902
PHOENIX CONTACT MCV 1,5/ 9-G-3,81 GY7035 MCV 1,5/ 9-G-3,81 GY7035 1711902 PHOENIX CONTACT Housing base printed circuit board, number of poles: 9, pit.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCV 1,5/ 9-G-3,81 GY7035 1711902 PHOENIX CONTACT Housing base printed circuit board, number of poles: 9, pit..

MCV 1,5/ 9-G-3,81 GY7035

1711902

PHOENIX CONTACT

50 Pcs.

Housing base printed circuit board, number of poles: 9, pitch: 3,81 mm, color: gray, surface contacts: Tin, assembly: wave Soldering Printed circuit board base housing, nominal section: 1.5 mm², color: luminous gray, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 9, number of rows: 1, number of poles: 9, number of connections: 9, family of articles: MCV 1.5/.. -G, pitch: 3.81 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Housing base printed circuit board, nominal current: 8 A, voltage and sizing (III/2): 160 V, number of poles: 9, pitch: 3,81 mm, color: gray, surface contacts: Tin, assembly: wave Soldering

Data commercial

Key orderOne million seven hundred eleven thousand nine hundred two
Packing unit50 pcs
Key sellingAAAEDA -
Minimum order quantity50 pcs
EANFour trillion fifty five billion six hundred twenty six million four hundred eighty seven thousand four hundred twenty seven
Unit weight (excluding packaging)2,264 g
Tariff number tariffEighty five million three hundred sixty six thousand nine hundred thirty

Dimensions

Length [ l ]7,25 mm
Width35,68 mm
Step3,81 mm
Average30,48 mm
Width [ w ]35,68 mm
Height [ h ]12,6 mm
Height of construction9,2 mm
Length of the pin welding3.4 mm
Dimensions of pin0.8 x 0.8 mm
Length7,25 mm

Overview

Family of articlesMCV 1,5/..-G -
Colorlight grey
Number of polesNine

Environmental Product Compliance

China RoHSSpace of time for the intended use: unlimited = FEUP-e
No dangerous substances above the thresholds

Ratings

eCl@ss

eCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 7.0Twenty seven million four hundred forty thousand four hundred two
eCl@ss 8.0Twenty seven million four hundred forty thousand four hundred two
eCl@ss 9.0Twenty seven million four hundred forty thousand four hundred two

ETIM

ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
