View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MCV 1,5/ 6-G-3,5 OG 1095532 PHOENIX CONTACT Housing base printed circuit board, number of poles: 6, pitch: 3..
MCV 1,5/ 6-G-3,5 OG
1095532
PHOENIX CONTACT
100 Pcs.
Housing base printed circuit board, number of poles: 6, pitch: 3.5 mm, color: orange
Printed circuit board base case, nominal section: 1.5 mm², color: orange, nominal current: 8 A, contact surface: Tin, contact connection type: Male, number of rows: 1, number of poles: 6, article family: MCV 1.5/.. -G, pitch: 3.5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1.5, Plug-in face orientation: Standard, locking: without, packaging type: boxed
PCB base strip, nominal cross-section: 1.5 mm2, color: orange, rated current: 8 A, contact surface: Sn, contact type: pin, number of rows: 1, number of poles: 6, article family: MCV 1,5/.. -G, Pitch: 3.5 mm, Mounting: Wave Soldering, Pin Layout: Linear Pinning, Pin Length [P]: 3.4 mm, Number of Solder Pins per Potential: 1, Mating System: COMBICON MC 1.5, Mating Face Alignment: Standard, Locking: None, Packaging Type: Packed in a Box
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Product Type | PCB Floor Strip |
| Product family | MCV 1.5/.. -G |
| Product Line | COMBICON Connectors S |
| Number of poles | 6 |
| Grid dimension | 3.5 mm |
| Number of rows | 1 |
| Pin layout | Linear Pinning |
| Number of solder pins per potential | 1 |
| Data maintenance status | |
| Article revision | 00 |
| Nominal current IN | 8 A |
| Rated voltage UN | 160 V |
| Mounting type | Wave Soldering |
| Pin layout | Linear Pinning |
| Material information - Contact | |
| Note | WEEE/RoHS compliant, whisker-free according to IEC 60068-2-82/JEDEC JESD 201 |
| Material Contact | Cu alloy |
| Surface finish | Electroplated |
| Metal Surface Contact Area (Top Layer) | Tin (3 - 5 μm Sn) |
| Metal Surface Contact Area (Interlayer) | Nickel (1.3 - 3 μm Ni) |
| Metal Surface Soldering Area (Top Layer) | Tin (3 - 5 μm Sn) |
| Metal Surface Soldering Area (Interlayer) | Nickel (1.3 - 3 μm Ni) |
| Material specifications - Housing | |
| Color (Housing) | orange (2003) |
| Insulating material | PA |
| Insulating material group | I |
| CTI according to IEC 60112 | 600 |
| Flammability class according to UL 94 | V0 |
| Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
| Temperature of the ball pressure test according to EN 60695-10-2 | 125 °C |
| Dimensional drawing |  |
| Grid dimension | 3.5 mm |
| Width [w] | 22.4 mm |
| Height [h] | 12.6 mm |
| Length [l] | 7.25 mm |
| Overall height | 9.2 mm |
| Solder pin length [P] | 3.4 mm |
| PCB Design | |
| Drill Hole Diameter | 1.2 mm |
| Environmental conditions | |
| Ambient temperature (operating) | -40 °C ... 100 °C (depending on the derating curve) |
| Ambient temperature (storage/transport) | -40 °C ... 70 °C |
| Relative humidity (storage/transport) | 30 % ... 70 % |
| Ambient temperature (mounting) | -5 °C ... 100 °C |
| Packaging type | packed in carton |
| Feature Name | Feature Value |
|---|---|
| Connector model (EF007495) | Fixed connector |
| Contact type (EF001587) | Pin |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 3.5 mm |
| Modular spacing connections (EF006827) | 3.5 mm |
| Rated current In (EF008250) | 8 A |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Material of contact surface (EF004020) | Tin |
| Type of electric connection (EF003961) | Other |
| Diameter connection pin (EF006823) | 1.2 mm |
| Length pin (EF006825) | 3.4 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Orange |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of banding (EF007011) | Carton (for SMD) |
