PHOENIX CONTACT MCV 1,5/ 2-G-3,5 BK CP2 MCV 1,5/ 2-G-3,5 BK CP2 1047050 PHOENIX CONTACT Housing base printed circuit board, number of poles: 2, pitc.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCV 1,5/ 2-G-3,5 BK CP2 1047050 PHOENIX CONTACT Housing base printed circuit board, number of poles: 2, pitc..

MCV 1,5/ 2-G-3,5 BK CP2

1047050

PHOENIX CONTACT

250 Pcs.

Housing base printed circuit board, number of poles: 2, pitch: 3.5 mm, color: black Printed circuit board base housing, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of rows: 1, number of poles: 2, family of articles: MCV 1.5/.. -G, pitch: 3.5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed PCB base socket, nominal cross-section: 1.5 mm2, colour: black, rated current: 8 A, dimensioning voltage (III/2): 160 V, contact surface: Sn, contact connection type: plug, number of rows: 1, number of poles: 2, product series: MCV 1.5/.. -G, pitch: 3.5 mm, mounting: Wave soldering, pin layout: Linear pinning, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug system: COMBICON MC 1.5, Insertion pin orientation: Standard, locking: none, fixing type: none, packaging type: packed in carton

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Product TypeBasic socket for printed circuit boards
Product FamilyMCV 1.5/.. -G
Product LineCOMBICON Connectors S
Number of poles2
Step3.5 mm
Number of rows1
Pin LayoutLinear Pinning
Number of Welding Pins per Potential1
Data maintenance status
Article review00
Rated Current IN8 A
Rated voltage UN160 V
Mass Resistivity1.8 mΩ
Sizing voltage (III/3)160 V
Sizing impulse voltage (III/3)2.5 kV
Sizing voltage (III/2)160 V
Sizing Impulse Voltage (III/2)2.5 kV
Sizing voltage (II/2)250 V
Sizing Impulse Voltage (II/2)2.5 kV
Mounting typeWave Soldering
Pin LayoutLinear Pinning
Material information - contacts
noteComplies with WEEE/RoHS, no thread-like materials according to IEC 60068-2-82/JEDEC JESD 201
Contact MaterialCu Alloy
Surface FinishGalvanic tin plating
Metal surface contact zone (surface layer)Tin (3 - 5 μm Sn)
Metal surface contact area (middle layer)Nickel (1 - 3 μm Ni)
Metal Surface Welding Area (Surface Layer)Tin (3 - 5 μm Sn)
Metal Surface Weld Area (Middle Layer)Nickel (1 - 3 μm Ni)
Material information - case
Color (Case)Black (9005)
Insulation materialPBT
Insulation Material GroupIIIa
CTI according to IEC 60112225
Combustibility class according to UL 94V0
Dimensioned Drawing
Step3.5 mm
Width [w]8.4 mm
Height [h]12.6 mm
Length [l]7.25 mm
Installation Height9.2 mm
Weld Shank Length [P]3.4 mm
Shank sizes0.8 x 0.8 mm
Printed circuit board design
Bore diameter1.2 mm
Visual inspection
Test SpecificationDIN EN 60512-1-1:2003-01
ResultTest passed
Dimensional control
Test SpecificationDIN EN 60512-1-2:2003-01
ResultTest passed
Resistance of lettering
Test SpecificationDIN EN 60068-2-70:1996-07
ResultTest passed
Polarization and encoding
Test SpecificationDIN EN 60512-13-5:2006-11
ResultTest passed
Contact holder in use
Test SpecificationDIN EN 60512-15-1:2009-03
Areas of application for contact holders
Application >20 N		Test passed
Insertion/tensile force
ResultTest passed
Number of cycles25
Insertion force per pole approx.6 N
Tensile force per pole approx.4 N
Thermal Test Control Group C
Test SpecificationDIN EN 60512-5-1:2003-01
Number of poles tested20
Insulation Resistance
Test SpecificationDIN EN 60512-3-1:2003-01
Insulation Resistance Between Contiguous Poles> 5 MΩ
Creepage and Creepage Distances
Test SpecificationDIN EN 60664-1 (VDE 0110-1):2008-01
Insulation Material GroupIIIa
Resistance to surface currents (DIN EN 60112 (VDE 0303-11))CTI 225
Rated insulation voltage (III/3)160 V
Rated impulse voltage (III/3)2.5 kV
Minimum clearance value - inhomogeneous range (III/3)1.5 mm
Minimum creepage value (III/3)2.5 mm
Rated Isolation Voltage (III/2)160 V
Rated impulse voltage (III/2)2.5 kV
Minimum creepage value - inhomogeneous range (III/2)1.5 mm
Minimum creepage value (III/2)1.6 mm
Rated Isolation Voltage (II/2)250 V
Rated Impulse Voltage (II/2)2.5 kV
Minimum creepage value - inhomogeneous range (II/2)1.5 mm
Minimum creepage value (II/2)2.5 mm
Vibration test
Test SpecificationDIN EN 60068-2-6 (VDE 0468-2-6):2008-10
Frequency10 - 150 - 10 Hz
Sweep Speed1 octave/min
Amplitude0.35 mm (10 Hz ... 60.1 Hz)
Acceleration5g (60.1 Hz ... 150 Hz)
Test duration per axle2.5 h
Test DirectionsX, Y, and Z axis
Electrical life control
Test SpecificationDIN IEC 60512-5:1994-05
Vertical impulse tension above sea level2.95 kV
Mass Resistivity R11.8 mΩ
Mass Resistivity R22.2 mΩ
Manoeuvring cycles25
Climate control
Test SpecificationDIN EN ISO 6988:1997-03
Stress due to corrosion0.2 dm3KNOW2on 300 dm3/40 °C/1 cycle
Stress due to the effect of heat100 °C/168 h
Fixed AC voltage1.39 kV
Environmental conditions
Ambient temperature (operating)-40 °C ... 100 °C (depending on derating curve)
Ambient temperature (storage/transport)-40 °C ... 70 °C
Relative humidity (transport and storage)30 % ... 70 %
Ambient temperature (mounting)-5 °C ... 100 °C
PackagingPacked in carton

ETIM for 1047050 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 3.5 mm
Modular spacing connections (EF006827) 3.5 mm
Rated current In (EF008250) 8 A
Rated voltage (EF000228) 160 V
Rated surge voltage (EF002993) 2.5 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.2 mm
Length pin (EF006825) 3.4 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Carton (for SMD)

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
