View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MCO 1,5/ 6-GL-3,81 BK 1701627 PHOENIX CONTACT Feed-through header
MCO 1,5/ 6-GL-3,81 BK
1701627
PHOENIX CONTACT
50 Pcs.
Feed-through header
Printed circuit board base case, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 6, family of articles: MCO 1.5/.. -GL, pitch: 3.81 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1.5, locking: without, fixing type: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Pitch | 3.81 mm |
|---|---|
| Dimension a | 19.05 mm |
| Height | 8 mm |
| Length of the solder pin | 3 mm |
| Pin dimensions | 0.9 x 0.32 mm |
General
| Range of articles | MCO 1,5/..-GL |
|---|---|
| Rated voltage (III/3) | 125 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 8 A |
| Color | black |
| Number of positions | 6 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
