PHOENIX CONTACT MC 1,5/2-STF-5,08 BD:-,+ MC 1,5/2-STF-5,08 BD:-,+ 1706908 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MC 1,5/2-STF-5,08 BD:-,+ 1706908 PHOENIX CONTACT Printed-circuit board connector

MC 1,5/2-STF-5,08 BD:-,+

1706908

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 1.5 mm², color: green, nominal current: 8 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, Number of potentials: 2, Number of rows: 1, Number of poles per row: 2, number of connections: 2, family of articles: MC 1.5/.. -STF, pitch: 5.08 mm, connection type: Screw connection with traction capsule, conductor connection direction/printed circuit board: 0°, Stecksystem: MINI COMBICON, Locking: Screw lock, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1706908
Packing unit1
GTIN4055626054322
Custom tariff number85366990

Dimensions

Length [ l ]15.5 mm
Width [ w ]19.32 mm
Height [ h ]11.1 mm
Pitch5.08 mm
Dimension a5.08 mm

General

Range of articlesMC 1,5/..-STF
Number of positions2
Connection methodScrew connection with tension sleeve
Nominal cross section1.5 mm²

Environmental Product Compliance

China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
