PHOENIX CONTACT MC 1,5/12-G-3,5 GY MC 1,5/12-G-3,5 GY 1029289 PHOENIX CONTACT Feed-through header MC 1,5/12-G-3,5 GY 1029289 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MC 1,5/12-G-3,5 GY 1029289 PHOENIX CONTACT Feed-through header MC 1,5/12-G-3,5 GY 1029289

MC 1,5/12-G-3,5 GY

1029289

PHOENIX CONTACT

1 Pcs.


Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Feed-through header - MC 1,5/12-G-3,5 GY - 1029289

Printed circuit board base housing, nominal section: 1.5 mm², color: gray, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 12, number of rows: 1, number of poles: 12, number of connections: 12, family of articles: MC 1.5/.. -G, pitch: 3.5 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1.5, Plug-in face orientation: Standard, locking: without, packaging type: boxed

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
