PHOENIX CONTACT MC 0,5/ 6-G-2,5 THT P14 R44 MC 0,5/ 6-G-2,5 THT P14 R44 1031961 PHOENIX CONTACT Feed-through header MC 0,5/ 6-G-2,5 THT P14 R44 1031961 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MC 0,5/ 6-G-2,5 THT P14 R44 1031961 PHOENIX CONTACT Feed-through header MC 0,5/ 6-G-2,5 THT P14 R44 1031961

MC 0,5/ 6-G-2,5 THT P14 R44

1031961

PHOENIX CONTACT

330 Pcs.

Feed-through header - MC 0,5/ 6-G-2,5 THT P14 R44 - 1031961 Printed circuit board base housing, nominal section: 0.5 mm², color: black, nominal current: 4 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 6, family of articles: MC 0.5/.. -G-THT, pitch: 2.5 mm, mounting: Weld THR, pin arrangement: Linear pin arrangement, pin length [P]: 1.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON FK-MC 0.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: 44 mm wide strap

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

PCB headers, nominal current: 4 A, rated voltage (III/2): 160 V, number of positions: 6, pitch: 2.5 mm, color: black, contact surface: Tin, mounting: THR soldering

Key Commercial Data

Orderkey1031961
Packing unit1
GTIN4055626536118
Custom tariff number85366930

Dimensions

Length [ l ]10.1 mm
Width16.9 mm
Pitch2.5 mm
Dimension a12.5 mm
Width [ w ]16.9 mm
Height [ h ]9.5 mm
Height8.1 mm
Length of the solder pin1.4 mm
Pin dimensions0.8 x 0.8 mm
Length10.1 mm

General

Range of articlesMC 0,5/..-G-THT
Colorblack
Number of positions6

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications

eCl@ss

eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440402
eCl@ss 8.027440402
eCl@ss 9.027440402

ETIM

ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637

ETIM for 1031961 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of poles (EF001391) 6
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 2.5 mm
Modular spacing connections (EF006827) 2.5 mm
Rated current In (EF008250) 4 A
Rated voltage (EF000228) 160 V
Rated surge voltage (EF002993) 2.5 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.4 mm
Length pin (EF006825) 1.4 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Other
