PHOENIX CONTACT MC 0,5/ 3-G-2,5 YE MC 0,5/ 3-G-2,5 YE 1873277 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MC 0,5/ 3-G-2,5 YE 1873277 PHOENIX CONTACT Feed-through header

MC 0,5/ 3-G-2,5 YE

1873277

PHOENIX CONTACT

50 Pcs.

Feed-through header Printed circuit board base housing, nominal section: 0.5 mm², color: yellow, nominal current: 4 A, nominal voltage (III/2): 160 V, contact surface: Sn, contact connection type: Male, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, article family: MC 0.5/.. -G, pitch: 2.5 mm, mounting: Wave soldering, conductor/printed circuit board connection direction: 0 °, pin arrangement: Linear pin arrangement, pin length [P]: 3.8 mm, number of solder pins per potential: 1, plug-in system: COMBICON FK-MC 0.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: Boxed Packaging

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1873277
Packing unit1
GTIN4055626186276
Custom tariff number85366930

Dimensions

Length [ l ]10.1 mm
Width9.4 mm
Pitch2.5 mm
Dimension a5 mm
Width [ w ]9.4 mm
Height [ h ]11.9 mm
Height8.1 mm
Length of the solder pin3.8 mm
Pin dimensions0.8 x 0.8 mm
Length10.1 mm

General

Range of articlesMC 0,5/..-G
Insulating material groupI
Rated voltage (III/2)160 V
Nominal current IN4 A
Flammability rating according to UL 94I
Coloryellow
Number of positions3

Standards and Regulations

Flammability rating according to UL 94I

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
