PHOENIX CONTACT VISU+ 2 RT-D 128 WEB3 AD VISU+ 2 RT-D 128 WEB3 AD 2701147 PHOENIX CONTACT Software View larger
Images are for illustrative purposes only. Please refer to data sheet for details

VISU+ 2 RT-D 128 WEB3 AD 2701147 PHOENIX CONTACT Software

VISU+ 2 RT-D 128 WEB3 AD

2701147

PHOENIX CONTACT

1 Pcs.

Software Runtime license for Visu+ including 3 WebClients and the alarm dispatcher function with a limitation of I/O data and variables in scripting to 128 bytes. In addition, 2 direct driver connections are possible. Runtime license for Visu+ including 3 web clients and alarm dispatcher function where the I/O data and variables in the scripting are limited to 128 bytes. In addition, 2 direct driver connections are possible.

Automation > Visualization software
Automation Software (AS)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Product properties
Product typeVisualization
System properties
Intended use for the softwareVisualization
License information
Type of licenseRuntime license
Functionality
Basic functionsKnow-How protection and safety through encoding of projects
Realtime database coupling with ODBC to MS ACCESS, MS EXCEL and SQL server
FDA CFR 21 Part 11 compatible
Expanded functionalityWeb client capability
Integrated functionOnline configuration
Password protection
Language selection
Alarm management
Web client
Number of I/O nodes128
Number of clients3
System requirements
Hard disk memorymin. 1 GByte (recommended: 2 GB)
RAMmin. 1 GByte (2 GB for Windows Vista and Windows 7)
Supported browsersInternet Explorer 5.5 or higher
Languages supportedGerman, English, French, Italian
Optical driveDVD-ROM
Screen resolution1024 x 768 pixel(s) (XGA)
System requirements for development environment
Operating equipmentKeyboard, mouse
Operating systemWindows® 11
Windows® 10
Windows® 8.1
Windows® 8
Windows® 7
Windows® Embedded Standard 7
Windows® Server 2019
Windows® Server 2016
Windows® Server 2012 R2
Windows® Server 2012
Windows® Server 2008 R2
Windows® Server 2008
Windows® Server 2003
System requirements for runtime environment
Operating systemWindows® 10
Windows® 8.1
Windows® 8
Windows® 7
Windows® Embedded Standard 7
Windows® XP Embedded
Windows® Server 2019
Windows® Server 2016
Windows® Server 2012 R2
Windows® Server 2012
Windows® Server 2008 R2
Windows® Server 2008
Windows® Server 2003
Windows® CE 5.0
Windows® CE 6.0
Windows® Mobile

ETIM for 2701147 PLC's (EC001416)
Feature Name Feature Value
With OPC-interface, server (EF003172) No
With OPC-interface, client (EF003173) No
With programming interfaces (EF003174) No
Multi-user capable, runtime (EF003152) No
Max. number of clients (EF003154) 0
Suitable for web-clients (EF003155) Yes
SCADA functionality (EF007458) No
Alarm-management (EF006805) No
Trend representation (EF007510) No
Online projecting possible (EF003158) Yes
Language switch possible (EF007493) Yes
With script language Visual Basic (EF003163) No
With other script language (EF003164) No
Library with object elements (EF003165) Not available
User groups (password protection) possible (EF003166) Yes
Function process diagnostics (EF003170) Not available
Min. required processor speed for runtime system (EF003175) 1.6 GHz
Min. required processor speed for configuration software (EF003181) 1.6 GHz
