PHOENIX CONTACT IPC 16/ 6-G-10,16 GY IPC 16/ 6-G-10,16 GY 1793095 PHOENIX CONTACT PCB headers, nominal current: 76 A, rated voltage (III/2): 1000.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IPC 16/ 6-G-10,16 GY 1793095 PHOENIX CONTACT PCB headers, nominal current: 76 A, rated voltage (III/2): 1000..

IPC 16/ 6-G-10,16 GY

1793095

PHOENIX CONTACT

50 Pcs.

PCB headers, nominal current: 76 A, rated voltage (III/2): 1000 V, number of positions: 6, pitch: 10.16 mm, color: gray, contact surface: Silver, mounting: Wave soldering Printed circuit board base housing, nominal section: 16 mm², color: gray, nominal current: 76 A, nominal voltage (III/2): 1000 V, contact surface: silver, contact type: Female, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 6, article family: IPC 16/.. -G, pitch: 10.16 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 4 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 16, Plug-in face orientation: Standard, locking: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

PCB headers, nominal current: 76 A, rated voltage (III/2): 1000 V, number of positions: 6, pitch: 10.16 mm, color: gray, contact surface: Silver, mounting: Wave soldering

Key Commercial Data

Orderkey1793095
Packing unit1
GTIN4046356620727
Custom tariff number85366930

Dimensions

Length [ l ]32.1 mm
Width61.76 mm
Pitch10.16 mm
Dimension a50.8 mm
Width [ w ]61.76 mm
Height [ h ]17.6 mm
Height13.6 mm
Length of the solder pin4 mm
Pin dimensions0.8 x 1.2 mm
Length32.1 mm

General

Range of articlesIPC 16/..-G
Rated voltage (III/3)1000 V
Nominal current IN76 A
Colorgray
Number of positions6

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications

eCl@ss

eCl@ss 4.0272607xx
eCl@ss 4.127260701
eCl@ss 5.027260701
eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440402
eCl@ss 8.027440402
eCl@ss 9.027440402

ETIM

ETIM 4.0EC002637
ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637

UNSPSC

UNSPSC 6.0130211810
UNSPSC 7.090139121409
UNSPSC 1139121409
UNSPSC 12.0139121409
UNSPSC 13.239121409
