View larger
Images are for illustrative purposes only. Please refer to data sheet for details
IMCV 1,5/ 8-G-3,81 AU 1713716 PHOENIX CONTACT Feed-through header
IMCV 1,5/ 8-G-3,81 AU
1713716
PHOENIX CONTACT
1000 Pcs.
Feed-through header
Printed circuit board base housing, nominal section: 1.5 mm², color: green, nominal current: 8 A, dimensioning voltage (III/2): 160 V, contact surface: Gold, contact type: Female connection, Number of potentials: 8, Number of rows: 1, Number of poles per row: 8, number of connections: 8, family of articles: IMCV 1.5/.. -G, pitch: 3.81 mm, mounting: Wave soldering, pin arrangement: Linear double pin arrangement, pin length [P]: 3.4 mm, Stecksystem: MINI COMBICON, Locking: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Key Commercial Data
| Orderkey | 1713716 |
|---|---|
| Packing unit | 50 pc |
| Minimum order quantity | 1000 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4046356091589 |
| Weight per Piece (excluding packing) | 2.740 g |
| Custom tariff number | 85366930 |
| Country of origin | PL (Poland) |
Dimensions
| Length [ l ] | 6.85 mm |
|---|---|
| Width | 31.27 mm |
| Pitch | 3.81 mm |
| Dimension a | 26.67 mm |
| Width [ w ] | 31.27 mm |
| Height [ h ] | 17.9 mm |
| Height | 14.5 mm |
| Length of the solder pin | 3.4 mm |
| Pin dimensions | 1.12 mm |
| Length | 6.85 mm |
General
| Range of articles | IMCV 1,5/..-G |
|---|---|
| Rated voltage (III/3) | 160 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 8 A |
| Color | green |
| Number of positions | 8 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
