PHOENIX CONTACT IMC 1,5/ 5-G-3,81 GY IMC 1,5/ 5-G-3,81 GY 1715832 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IMC 1,5/ 5-G-3,81 GY 1715832 PHOENIX CONTACT Feed-through header

IMC 1,5/ 5-G-3,81 GY

1715832

PHOENIX CONTACT

50 Pcs.

Feed-through header Printed circuit board base housing, nominal section: 1.5 mm², color: gray, nominal current: 8 A, dimensioning voltage (III/2): 160 V, contact surface: Tin, contact type: Female connection, Number of potentials: 5, Number of definitions: 1, Number of poles per row: 5, number of connections: 5, family of articles: BMI 1.5/.. -G, pitch: 3.81 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, Stecksystem: MINI COMBICON, Locking: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1715832
Packing unit1
GTIN4055626428864
Custom tariff number85366930

Dimensions

Length [ l ]14.45 mm
Width19.84 mm
Pitch3.81 mm
Dimension a15.24 mm
Width [ w ]19.84 mm
Height [ h ]10.25 mm
Height6.85 mm
Length of the solder pin3.4 mm
Pin dimensions0.62 x 1.12 mm
Length14.45 mm

General

Range of articlesIMC 1,5/..-G
Colorgray
Number of positions5

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
