View larger
Images are for illustrative purposes only. Please refer to data sheet for details
ICV 2,5/ 4-GF-5,08 GY 1702447 PHOENIX CONTACT Printed-circuit board connector
ICV 2,5/ 4-GF-5,08 GY
1702447
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Printed circuit board base case, nominal section: 2.5 mm², color: gray, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, article family: ICV 2.5/.. -GF, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.6 mm, number of solder pins per potential: 2, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: Screw lock, fixing type: Air clamping (thread), packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 10.2 mm |
|---|---|
| Width | 30.44 mm |
| Pitch | 5.08 mm |
| Dimension a | 15.24 mm |
| Width [ w ] | 30.44 mm |
| Height [ h ] | 22.6 mm |
| Height | 19 mm |
| Length of the solder pin | 3.6 mm |
| Pin dimensions | 0.5 x 1.14 mm |
| Length | 10.2 mm |
General
| Range of articles | ICV 2,5/..-GF |
|---|---|
| Rated voltage (III/3) | 320 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 12 A |
| Color | gray |
| Number of positions | 4 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
