View larger
Images are for illustrative purposes only. Please refer to data sheet for details
IC-DFR 6 BK 1574524 PHOENIX CONTACT Recessed frame, color: black, article family: IC-DFR, width: 54.15 mm
IC-DFR 6 BK
1574524
PHOENIX CONTACT
1000 Pcs.
Recessed frame, color: black, article family: IC-DFR, width: 54.15 mm
Recessed Frame, Accessories
Panel mounting frame, Accessories, color: black, product range: IC-DFR, width: 54.15 mm
Connectors > Accessories/spare parts for industrial connectors
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Product properties
| Product line | COMBICON Connectors Special |
| Product type | Panel mounting frame |
| Product family | IC-DFR |
| Number of positions | 6 |
| Pitch | 5.08 mm |
| Number of rows | 1 |
Electrical properties
| Degree of pollution | 3 |
Dimensions
| Dimensional drawing |  |
| Pitch | 5.08 mm |
| Width [w] | 54.15 mm |
| Height [h] | 16.75 mm |
| Length [l] | 19 mm |
Material specifications
| Material data - housing | |
| Color (Housing) | black (9005) |
| Insulating material | PA |
| Insulating material group | I |
| CTI according to IEC 60112 | 600 |
| Flammability rating according to UL 94 | V0 |
| Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
| Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
Connector
| Connection 1 | |
| Insulating material | PA |
| CTI according to IEC 60112 | 600 |
Packaging specifications
| Type of packaging | packed in cardboard |
