PHOENIX CONTACT PST 1,3/14-H-5,0 PST 1,3/14-H-5,0 1717372 PHOENIX CONTACT Pin strip View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PST 1,3/14-H-5,0 1717372 PHOENIX CONTACT Pin strip

PST 1,3/14-H-5,0

1717372

PHOENIX CONTACT

50 Pcs.

Pin strip Male connector, nominal section: 1.5 mm², color: black, nominal current: 12 A (Depending on the connector used), nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 14, number of rows: 1, number of poles: 14, number of connections: 14, family of articles: PST 1.3/.. -H, pitch: 5 mm, mounting: Solder THR, pin arrangement: Linear pin arrangement, pin length [P]: 6.8 mm, plug-in system: COMBICON PST 1.3, locking: without, fixing type: without, packaging type: boxed, The maximum current depends on the connector used. Of the two current values, the lower value for the connector and the male connector is decisive. The plug is made of high-temperature resistant plastic, making it suitable for the reflow soldering process.

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1717372
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
Catalog pagePage 435 (C-1-2013)
GTIN4046356138734
Weight per Piece (excluding packing)3.410 g
Custom tariff number85366930
Country of originSK (Slovakia)

Dimensions

Length [ l ]12.5 mm
Width70 mm
Pitch5 mm
Dimension a65 mm
Width [ w ]70 mm
Height [ h ]2.8 mm
Height2.8 mm
Pin dimensionsø 1.3 mm
Length12.5 mm

General

Range of articlesPST 1,3/..-H
Insulating material groupIIIa
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Rated voltage (III/3)250 V
Rated voltage (III/2)320 V
Rated voltage (II/2)400 V
Connection in acc. with standardEN-VDE
Nominal current IN12 A (depends on the plug used)
Maximum load current12 A (depends on the plug used)
Insulating materialPA
Flammability rating according to UL 94V0
Colorblack
Number of positions14

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
