View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MCDN 1,5/ 5-G1-3,5 RNP26THR 1953554 PHOENIX CONTACT Feed-through header
MCDN 1,5/ 5-G1-3,5 RNP26THR
1953554
PHOENIX CONTACT
1 Pcs.
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲
Feed-through header
Base housing printed circuit board, nominal section: 1.5 mm², color: black, rated current: 8 A, sizing voltage (III/2): 160 V, surface contacts: Tin, contact type: Male, Number of potentials: 10, Number of rows: 2,Number of poles per row: 5, number of connections: 10, article family: MCDN 1.5/.. -G1-RN-THR, pitch: 3.5 mm, mounting: WELDING THR, pin arrangement: Linear pin arrangement, pin length [P]: 2.6 mm, Stecksystem: MINI COMBICON, Locking: Lace lock, packaging type: boxed packaging, Item with lace protrusion. The pin length is 2.6 mm. For user information and design recommendations on Through Hole Reflow technology, see under: "Downloads"
Base housing printed circuit board, nominal section: 1.5 mm², color: black, rated current: 8 A, sizing voltage (III/2): 160 V, surface contacts: Tin, contact type: Male, Number of potentials: 10, Number of rows: 2,Number of poles per row: 5, number of connections: 10, article family: MCDN 1.5/.. -G1-RN-THR, pitch: 3.5 mm, mounting: WELDING THR, pin arrangement: Linear pin arrangement, pin length [P]: 2.6 mm, Stecksystem: MINI COMBICON, Locking: Lace lock, packaging type: boxed packaging, Item with lace protrusion. The pin length is 2.6 mm. For user information and design recommendations on Through Hole Reflow technology, see under: "Downloads"
