PHOENIX CONTACT IC 2,5 HC/ 5-GF-5,08 IC 2,5 HC/ 5-GF-5,08 1943454 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

IC 2,5 HC/ 5-GF-5,08 1943454 PHOENIX CONTACT Feed-through header

IC 2,5 HC/ 5-GF-5,08

1943454

PHOENIX CONTACT

50 Pcs.

Feed-through header Base housing printed circuit board, nominal section: 2.5 mm², colour: green, rated current: 16 A, sizing voltage (III/2): 320 V, surface contacts: Tin, contact type: Connecting female, Number of potentials: 5, Number of rows: 1, Number of poles per row: 5, number of connections: 5, article family: IC 2.5 HC/.. -GF, pitch: 5.08 mm, mounting: Wave welding, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, Stecksystem: POWER COMBICON 2.5, Locking: Screw locking, packaging type: boxed, COMBICON connectors should be operated only in an inert state (no load). If for reasons of technical operation smaller loads have to be connected, we can offer practical values, on request

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1943454
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
Catalog pagePage 499 (C-1-2013)
GTIN4017918878580
Weight per Piece (excluding packing)4.520 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]19 mm
Width35.52 mm
Pitch5.08 mm
Dimension a20.32 mm
Width [ w ]35.52 mm
Height [ h ]13.7 mm
Height10.2 mm
Length of the solder pin3.5 mm
Pin dimensions0.48 x 1.14 mm
Pin spacing5.08 mm
Length19 mm

General

Range of articlesIC 2,5 HC/..-GF
Insulating material groupI
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Rated voltage (III/3)320 V
Rated voltage (III/2)320 V
Rated voltage (II/2)630 V
Connection in acc. with standardEN-VDE
Nominal current IN16 A
Maximum load current16 A
Insulating materialPA
Flammability rating according to UL 94V0
Colorgreen
Number of positions5

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
