PHOENIX CONTACT DMCV 1,5/ 3-G1-3,5 P20THR DMCV 1,5/ 3-G1-3,5 P20THR 1787218 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

DMCV 1,5/ 3-G1-3,5 P20THR 1787218 PHOENIX CONTACT Printed-circuit board connector

DMCV 1,5/ 3-G1-3,5 P20THR

1787218

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Printed circuit board base housing, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 6, number of rows: 2, number of poles: 3, number of connections: 6, article family: DMCV 1.5/.. -G1-THR, pitch: 3.5 mm, mounting: Solder THR, pin arrangement: Linear pin arrangement, pin length [P]: 2 mm, number of solder pins per potential: 1, plug-in system: COMBICON DFMC 1.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1787218
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
Catalog pagePage 187 (C-1-2013)
GTIN4046356596831
Weight per Piece (excluding packing)1.290 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]10.6 mm
Width11.3 mm
Pitch3.5 mm
Dimension a7 mm
Width [ w ]11.3 mm
Height [ h ]12 mm
Height10 mm
Length of the solder pin2 mm
Pin dimensions0.8 x 0.8 mm
Pin spacing5.50 mm
Length10.6 mm

General

Range of articlesDMCV 1,5/..-G1-THR
Insulating material groupIIIa
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)160 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN8 A
Maximum load current8 A
Insulating materialLCP
Flammability rating according to UL 94V0
Colorblack
Number of positions3

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
