PHOENIX CONTACT MCV 0,5/ 4-G-2,54 P20 THR R24 MCV 0,5/ 4-G-2,54 P20 THR R24 1821410 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MCV 0,5/ 4-G-2,54 P20 THR R24 1821410 PHOENIX CONTACT Printed-circuit board connector

MCV 0,5/ 4-G-2,54 P20 THR R24

1821410

PHOENIX CONTACT

315 Pcs.

Printed-circuit board connector Printed circuit board base housing, nominal section: 0.5 mm², color: black, nominal current: 6 A, nominal voltage (III/2): 160 V, contact surface: Gold, contact type: Male, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: MCV 0.5/.. -G-THR, pitch: 2.54 mm, mounting: Weld THR, pin arrangement: Linear pin arrangement, pin length [P]: 2 mm, number of solder pins per potential: 1, plug-in system: COMBICON FMC 0.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: 24 mm wide strap, Sample quantities available under SAMPLE MC...

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1821410
Packing unit315 pc
Minimum order quantity315 pc
Catalog pagePage 177 (C-1-2013)
GTIN4046356789578
Weight per Piece (excluding packing)1.970 g
Custom tariff number85366930
Country of originPL (Poland)

Dimensions

Length [ l ]4.85 mm
Width14.74 mm
Pitch2.54 mm
Dimension a7.62 mm
Width [ w ]14.74 mm
Height [ h ]9.1 mm
Height7.1 mm
Length of the solder pin2 mm
Pin dimensions0.64 x 0.64 mm
Length4.85 mm

General

Range of articlesMCV 0,5/..-G-THR
Insulating material groupIIIa
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)32 V
Rated voltage (III/2)160 V
Rated voltage (II/2)160 V
Connection in acc. with standardEN-VDE
Nominal current IN6 A
Insulating materialLCP
Flammability rating according to UL 94V0
Colorblack
Number of positions4

Standards and Regulations

Connection in acc. with standardEN-VDE
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
