PHOENIX CONTACT MC 0,5/ 3-G-2,54 P20THRR24C1 MC 0,5/ 3-G-2,54 P20THRR24C1 1706224 PHOENIX CONTACT Header, Nominal current: 6 A, Rated voltage (III/2): 16.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

MC 0,5/ 3-G-2,54 P20THRR24C1 1706224 PHOENIX CONTACT Header, Nominal current: 6 A, Rated voltage (III/2): 16..

MC 0,5/ 3-G-2,54 P20THRR24C1

1706224

PHOENIX CONTACT

1 Pcs.


Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Header, Nominal current: 6 A, Rated voltage (III/2): 160 V, Number of positions: 3, Pitch: 2.54 mm, Color: black, Contact surface: Gold, Mounting: Taped SMD/THT/THR components, Fixed coding of the first position, can be combined with the FMC 0,5/...-ST-2,54 C1 connector

Printed circuit board base housing, nominal section: 0.5 mm², color: black, nominal current: 6 A, dimensioning voltage (III/2): 160 V, contact surface: Gold, contact type: Male, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, family of articles: MC 0.5/.. -G-THR, pitch: 2.54 mm, mounting: Weld THR, pin arrangement: Linear pin arrangement, pin length [P]: 2 mm, Stecksystem: MICRO COMBICON - FMC 0.5, Lock: without, packaging type: 24 mm wide strap, Fixed first pole coding, can be combined with FMC connector 0.5/...-ST-2.54 C1
