View larger
Images are for illustrative purposes only. Please refer to data sheet for details
HC-MOT-AFL 2 VPE 50 1470964 PHOENIX CONTACT Housing, Item Family: VARIOCON
HC-MOT-AFL_2 VPE 50
1470964
PHOENIX CONTACT
50 Pcs.
Housing, Item Family: VARIOCON
Housing, Range of articles: VARIOCON
Connectors > Housing for rectangular connectors
Field Device Connectors (FDC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Product properties
| Product type | Housing with locking latch |
| Product family | VARIOCON |
Dimensions
| Width | 90 mm |
| Height | 47 mm |
| Length | 90 mm |
Material specifications
| Material | Die-cast zinc |
Environmental and real-life conditions
| Ambient conditions | |
| Degree of protection | IP67 |
| Ambient temperature (operation) | -30 °C ... 100 °C |
| Feature Name | Feature Value |
|---|---|
| Width (EF000008) | 90 mm |
| Height (EF000040) | 47 mm |
| Depth (EF000049) | 90 mm |
| Coating housing (EF001601) | Other |
| Position cable feed (EF008218) | Other |
| With cable screw gland (EF000735) | No |
| Mounting method of the cable gland (EF012210) | Other |
| With hinged lid (EF000117) | No |
| With distance piece (EF005072) | No |
| With sealing (EF005610) | No |
| Operating temperature (EF002393) | -30 °C |
| EMC-version (EF001062) | No |
| Degree of protection (IP), mounted (EF007466) | IP67 |
