PHOENIX CONTACT GMSTBVA 2,5/12-G-7,62 BK GMSTBVA 2,5/12-G-7,62 BK 1736959 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

GMSTBVA 2,5/12-G-7,62 BK 1736959 PHOENIX CONTACT Feed-through header

GMSTBVA 2,5/12-G-7,62 BK

1736959

PHOENIX CONTACT

50 Pcs.

Feed-through header Printed circuit board base case, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of potentials: 12, number of rows: 1, number of poles: 12, number of connections: 12, article family: GMSTBVA 2.5/.. -G, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: without, fixing type: without, packaging type: boxed PCB header, nominal cross-section: 2.5 mm2, colour: black, nominal current: 12 A, reference voltage (III/2): 630 V, contact area: Sn, contact type: Male, number of potentials: 12, number of rows: 1, number of poles: 12, number of connections: 12, article range: GMSTBVA 2.5/.. -G, pitch: 7.62 mm, mounting: Wave welding, spindle plane: Linear pinout, spindle length [P]: 3.9 mm, number of pins per potential: 1, Plug-in system: COMBICON MSTB 2.5, Orientation of the plug-in pattern: Standard, Locking: without, Fastening type: without, Packaging type: packed in a carton

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1736959
Packing unit50 pc
NoteMade to Order (non-returnable)
GTIN4017918222826
Weight per Piece (excluding packing)5.870 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]8.6 mm
Width91.44 mm
Pitch7.62 mm
Dimension a83.82 mm
Width [ w ]91.44 mm
Height [ h ]15.9 mm
Height12 mm
Length of the solder pin3.9 mm
Pin dimensions1 x 1 mm
Length8.6 mm

General

Range of articlesGMSTBVA 2,5/..-G
Insulating material groupI
Rated surge voltage (III/3)6 kV
Rated surge voltage (III/2)6 kV
Rated surge voltage (II/2)6 kV
Rated voltage (III/3)400 V
Rated voltage (III/2)400 V
Rated voltage (II/2)1000 V
Connection in acc. with standardEN-VDE
Nominal current IN12 A
Maximum load current12 A
Insulating materialPA
Flammability rating according to UL 94V0
Colorblack
Number of positions12

Standards and Regulations

Connection in acc. with standardEN-VDE
CSA
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
