View larger
Images are for illustrative purposes only. Please refer to data sheet for details
PTSA 1,5/16-3,5-F OG 1710357 PHOENIX CONTACT Spring-cage PCB terminal block
PTSA 1,5/16-3,5-F OG
1710357
PHOENIX CONTACT
60 Pcs.
Spring-cage PCB terminal block
Terminal block for printed circuit board, nominal current: 8 A, dimensioning voltage (III/2): 250 V, nominal section: 1.5 mm², Number of potentials: 16, Number of rows: 1, Number of poles per row: 16, article family: PTSA 1.5, pitch: 3.5mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45 °, color: orange, Pin arrangement: Front linear pin arrangement, Pin length [P]: 3.6 mm, packaging type: boxed packaging. Welding pins in the anterior area, one row
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 3.5 mm |
| Dimension a | 52.5 mm |
| Width [ w ] | 57.5 mm |
| Height | 13.1 mm |
| Height [ h ] | 16.7 mm |
| Solder pin [P] | 3.6 mm |
| Pin spacing | 3.5 mm |
| Hole diameter | 1 mm |
General
| Range of articles | PTSA 1,5 |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 250 V |
| Nominal current IN | 8 A |
| Nominal cross section | 1.5 mm² |
| Solder pin surface | |
| Flammability rating according to UL 94 | V0 |
| Number of positions | 16 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
