PHOENIX CONTACT FKCN 2,5/ 3-ST-5,08BD14-12 SO FKCN 2,5/ 3-ST-5,08BD14-12 SO 1003381 PHOENIX CONTACT Connector for printed circuit board, number of poles: .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FKCN 2,5/ 3-ST-5,08BD14-12 SO 1003381 PHOENIX CONTACT Connector for printed circuit board, number of poles: ..

FKCN 2,5/ 3-ST-5,08BD14-12 SO

1003381

PHOENIX CONTACT

50 Pcs.

Connector for printed circuit board, number of poles: 3, pitch: 5,08 mm, connection type: spring clamp push-in, color: green, surface contacts: Tin Connector for printed circuit board, nominal section: 2.5 mm², color: green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, family of articles: FKCN 2.5/.. -ST, pitch: 5.08 mm, connection type: Push-in spring connection, conductor connection/printed circuit board connection direction: 0 °, clamping hook: - Clamping hook, plug-in system: COMBICON MSTB 2.5, locking: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Male connector for IC, nominal current: 12 A, rated voltage (III/2): 320 V, number of poles: 3, pitch: 5.08 mm, connection type: Push-in spring connection, colour: green, contact surface: tin

Business Data

Order Code1003381
Packaging unit1
GTIN4055626465791
Customs Tariff Number85366990

Dimensions

Length [ l ]27.1 mm
Width [ w ]15 mm
Height [ h ]10.9 mm
Steps5.08 mm
A-Rated10 mm

General

Article familyFKCN 2,5/.. -ST
Number of poles3
Connection typePush-in spring connection
Nominal cross-section2.5 mm²

Environmental Product Compliance

China RoHSPeriod of use in accordance with the rules: unlimited = EFUP-e
No hazardous substances exceeding the threshold values;

Classifications

eCl@ss

eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440309
eCl@ss 8.027440309
eCl@ss 9.027440309

ETIM

ETIM 5.0EC002638
ETIM 6.0EC002638
ETIM 7.0EC002638

ETIM for 1003381 Connectors (EC002638)
Feature Name Feature Value
Type of connection (EF000064) Other
Contact type (EF001587) Bus
Number of poles (EF001391) 3
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 5.08 mm
Modular spacing connections (EF006827) 5.08 mm
Angle contact/conductor connection (EF007546) Other
Rated current In (EF008250) 12 A
Rated voltage (EF000228) 320 V
Rated surge voltage (EF002993) 4 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connectable conductor cross section fine-strand without cable end sleeve (EF007341) 0.2 mm²
Connectable conductor cross section fine-strand with cable end sleeve (EF007339) 0.25 mm²
Connectable conductor cross section solid-core (EF007337) 0.2 mm²
Type of electric connection (EF003961) Spring clamp connection
Connectable cable type (EF006816) Tubular cable
Material of contact surface (EF004020) Tin
Material contact (EF007544) Copper
Material insulation body (EF007543) Other
Housing material (EF001596) Other
Housing colour (EF000136) Green
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
