View larger
Images are for illustrative purposes only. Please refer to data sheet for details
FK-MCP/ 4-12-ST-3,81BD SET 1708571 PHOENIX CONTACT PCB connector
FK-MCP/ 4-12-ST-3,81BD SET
1708571
PHOENIX CONTACT
50 Pcs.
PCB connector
Printed circuit board connector
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General
| Range of articles | FK-MCP 1,5/..-ST |
|---|---|
| Number of positions | 2 |
| Connection method | Push-in spring connection |
| Rated voltage (III/3) | 160 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 8 A |
| Nominal cross section | 1.5 mm² |
Connection data
| Conductor cross section solid min. | 0.14 mm² |
|---|---|
| Conductor cross section solid max. | 1.5 mm² |
| Conductor cross section flexible min. | 0.14 mm² |
| Conductor cross section flexible max. | 1.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. | 1.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 0.5 mm² |
| Conductor cross section AWG min. | 26 |
| Conductor cross section AWG max. | 16 |
Specifications for ferrules
| Recommended crimping pliers | 1212034 CRIMPFOX 6 |
|---|---|
| Ferrules without insulating collar, according to DIN 46228‑1 | Cross section: 0.25 mm²; Length: 7 mm ... 9 mm |
| Cross section: 0.34 mm²; Length: 7 mm ... 9 mm | |
| Cross section: 0.5 mm²; Length: 8 mm ... 9 mm | |
| Cross section: 0.75 mm²; Length: 8 mm ... 9 mm | |
| Cross section: 1 mm²; Length: 8 mm ... 9 mm | |
| Cross section: 1.5 mm²; Length: 8 mm ... 9 mm |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
