PHOENIX CONTACT FKC 2,5 HC/ 7-ST-5,08BKLCBUBD2 FKC 2,5 HC/ 7-ST-5,08BKLCBUBD2 1715182 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FKC 2,5 HC/ 7-ST-5,08BKLCBUBD2 1715182 PHOENIX CONTACT Printed-circuit board connector

FKC 2,5 HC/ 7-ST-5,08BKLCBUBD2

1715182

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 2.5 mm², color: black, nominal current: 16 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 7, number of rows: 1, number of poles: 7, number of connections: 7, article family: FKC 2.5 HC/.. -ST, pitch: 5.08 mm, connection type: Push-in spring connection, conductor connection direction/printed circuit board: 0 °, clamping hook: - Clamping hook, plug-in system: COMBICON MSTB 2.5 HC, locking: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1715182
Packing unit1
GTIN4055626437484
Custom tariff number85366990

Dimensions

Length [ l ]25.73 mm
Width [ w ]36.18 mm
Height [ h ]15 mm
Pitch5.08 mm
Dimension a30.48 mm

General

Range of articlesFKC 2,5 HC/..-ST
Number of positions7
Nominal cross section2.5 mm²

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
